High Pressure Fog Nozzle

Introducing our High Pressure 20-100bar Fog Nozzle, made with a brass body and stainless steel orifice, these 3/16″ male thread nozzles offer durability and optimal performance.

Key Features:

Versatile Nozzle Options: Choose from a range of orifice sizes (0.1mm, 0.15mm, 0.2mm, 0.3mm, 0.4mm, 0.5mm) to cater to specific misting needs, providing flexibility for various applications such as humidification, dust removal, cooling, and landscaping.

High-Performance Atomization: Operating at pressures of 20-100 bar, our fog nozzles deliver exceptional atomization rates, ranging from 0.03L/min to 0.19L/min based on the selected nozzle size.

Anti-Drop Design: Designed with an anti-drop, these nozzles prevent unwanted dripping. The liquid flows under pressure, forming a centrifugal vortex that results in a fine fog spray.

Cost-Effective Solution: Made from high-quality brass, our high pressure nozzles provide a cost-effective alternative to air humidification, offering substantial savings without compromising on performance.

Specifications:

• Product Name: 3/16″ Male Thread High Pressure Fog Nozzles
• Material: Brass body with stainless steel orifice
• Connection Size: 10-24UNC (3/16″ Thread)
• Orifice Options: 0.1mm, 0.15mm, 0.2mm, 0.3mm, 0.4mm, 0.5mm
• Pressure: 20~100 bar
• Application: Humidification, Dust Removal, Cooling, Landscaping

Upgrade your fog system with our High Pressure Nozzle – a reliable and cost-effective solution for efficient humidification, cooling, and more.
